16.6 millisecond automatic transfer between line and battery power supports UPS protection during blackouts and voltage fluctuations for equipment
compatible with a one cycle transfer time
750 watts continuous AC output in inverter mode, 1500 watts continuous AC output in AC mode
Double Boost? inverter output supports momentary start-up loads up to 200% of the continuous rating for up to 10 seconds
OverPower? inverter output supports longer duration overloads to 150% for 1-60 minutes under ideal battery and temperature conditions. (For best
results, utilize OverPower usage for as short of a duration as possible, ensure battery bank and cabling is able to provide full nominal DC voltage under
load and allow inverter/charger to fully cool before and after OverPower usage.)
3 stage, 20 amp battery charger with adjustable settings for wet/gel battery types offers fast, reliable battery recharging
Protected hardwire bolt-down input lugs safely accept heavy gauge input wiring from attached battery bank
Two built-in NEMA 5-15R output receptacles pass 120V line power or inverter output through to connected equipment
Reliability enhanced large-transformer design with secure mounting flanges and protected DC wiring terminals
Moisture-resistant construction enables vehicular or marine operation in high humidity environments
3 position operating mode switch supports "AUTO" mode to enable automatic transfer between DC and AC modes, CHARGE-ONLY to maintain a full
battery charge when AC is present without auto transfer and SYSTEM OFF settings.
Set of six front panel LEDs display AC/DC operational modes, overload status, DC voltage level, shutdown status and system fault status
Set of 4 configuration dip-switches support wet/gel battery charging profiles, adjustable 135/145V high voltage auto transfer during overvoltages and
selectable 75/85/95/105V AC low voltage auto transfer during brownouts
Resettable 6A charger AC input breaker and resettable 8A AC output breaker and automatic 2 speed cooling fan protect the inverter from load and
temperature related failures
Grounding lug properly connects the inverter/charger system to earth ground or vehicle grounding system
Automatic overload and thermal shutoff safely turns off inverter as excessive loads or overheating conditions develop
Front panel remote control connector enables remote off/on switching (requires APSRM4 switch accessory). Optional APSRM4 accessory also includes
user configurable jacks to support inverter shutoff or start-up as a vehicle ignition is engaged.
Specifications
OVERVIEW
Intended Application
OUTPUT
Frequency compatibility
Output watts
Continuous output capacity (watts)
Peak output capacity (watts)
Output nominal voltage
Output voltage regulation
Output frequency regulation
Overload protection
Outlet quantity / type
Emergency Home Power
60 Hz
750
750
1500
120V
LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains PWM sine wave output voltage of 120 V AC (+/-5%).
60 Hz (+/- 0.3 Hz)
Includes 6A AC input breaker dedicated to the charging system and 8A output breaker for AC output loads
2 NEMA 5-15R
2 / 5
